Facilities and Equipment

The mm-wave laboratory includes 54 m2 of a well equipped RF lab including a number of high quality instrument and an ALMA compatible cryostat. The machine shop is a 80 m2 facility where we fabricate microwave devices and support the design and implementation of test set-ups. It includes a CNC milling machine of 1 micrometer of accuracy. 27 m2 are used for storage, cryogenic and air compressors.


X
High precision lathe :

- 250-CNC, SHAUBLIN machines S.A , Switzerland
- Turning machine, resolution z-axis, 0.001mm
Datasheet

X

X
v

X

X


X
Vacuum and cryogenic equipment:

- Turbomolecular pumps (Pfeiffer turbocube)
- Leak detector (Pfeiffer HLT570)
- Vacuum sensors
- Temperature monitor (Lakeshore 218)
- ALMA test cryostat (NAOJ)
- 3 stage closed cycle helium system (Sumitomo CNA-61D)
- 2 stage closed system helium system (APD cryogenics)

X

X


X
Keysight PNA Network Analyzer E8364C:

- Network analysis for transmission line, microwave devices and antenna measurements.
- 10 MHz to 50 GHz.
- 104 dB of dynamic range and <0.006 dB trace noise.
- Datasheet


X
Keysight PXA Signal Analyzer N9030A:

- High precision spectrum analyzer.
- 3Hz to 50 GHz.
- Waveguide Harmonic Mixers (50-75 GHz,75-110 GHz y 220 -330 GHz).
- Datasheet


X
Keysight PSG Signal Generator E8257D:

- 2 to 20 GHz.
- Agilent mm-wave Source Module 83554A (20- 40GHz).
- OML Frequency Extension (50-75 GHz y 75-110 GHz).
- VDI Frequency Extension (220-330 GHz).
- Datasheet


X
Other RF Equipment:

- Erickson Instruments Power Meter PM3 (>75 GHz ).
- Keysight EPM Power Meter (<18 GHz).
- Anritsu Signal Generator MG3694C (2-40 GHz).
- Keysight EXG Signal Generator N5171B (<6GHz).
- R&S Signal Generator SMB110A (<3.2GHz).
- Keysight CXA Signal Analyzer N9000A (<26.5 GHz).
- Instrumentation amplifier 2 - 50 GHz.


X
Anechoic Chamber:

- Eccosorb Anechoic chamber (0.8 x 0.8 x 0.6m).
- Optical table (1.5 x 1m) and accessories.
- Near field Beam Scanner (1.6 µm resolution at 4,000 counts/rev) for measurements of optic systems.
- Frequency range: 33 to 50 GHz and 67 to 116 GHz with two different configurations.
- Datasheet

X

X


X
Software and simulation tools:

- Ansys Electronic Desktop with High Frequency Structure Simulator.
- Cadence AWR Microwave Office.
- WASP-NET.
- Topsolid.
- Books covering microwave fundamentals, Antenna theory and design, Microwave design, Quasi-optical propagation.

X

X

X


X
Mechanic shop:

- CNC precision machine, precision 1um, 5 axis (Kern)
- Measurement microscope, precision 1 um (Mitutoyo)
- Centering microscope 40x
- Turning machine
- Milling machine
- Facilities for micro-assembly (heating plate, precision scale, solder station, stereo microscopes …)
- Access to bonding machine at DIE.


X
Kulicke and Soffa Model 4526 Wire Bonder.

- Semi-automatic bonding machine.
- Equipped with microscope.
- 12.7-76um Gold wire diameter.
- Brochure

X

X

X


X
Cascade Microtech MPS150.

- Probe Station for high precision DC and RF measurements.
- Measurements up to 50 GHz.
- Motic PSM 1000 20X – 2000X Microscope.v - 50um and 150um spacing coplanar RF probes.
- Datasheet


X
Back-End/ROACH:

- 1x ROACH-1 (Virtex-5 FPGA).
- 4x ROACH-2 (Virtex-6 FPGA).
- 2x 3GSPS ADCs.
- 8x 5GSPS ADCs.
- 2x 16 Channels ADCs 250MSPS ADCs.
- Xilinx license for FPGA programming.



X
Chemical Facilities:

- Gold plating
- Nickel plating
- Several solutions and vessels for these purposes
- Gas extractor bench


X
Southern Millimeter Wave Telescope (SMWT).

-Operational telescope for research and education.
-1.2 m Cassegrain antenna.
-2SB Subharmonic Receiver (80-116 GHz).
-Digital spectrometer implemented in ROACH with digital sideband separation.

X

X

X

Circuit Card Prototyping Station


X
Laser Prototyping Machine 2um precision


X
Complementary PCB Milling Machine
